Zoom LiveTrak L-12 Digital Mixer & Multitrack Recorder Bundle Instruction Manual

ভূমিকা

This manual provides comprehensive instructions for the setup, operation, and maintenance of your Zoom LiveTrak L-12 Digital Mixer & Multitrack Recorder Bundle. Please read this manual thoroughly before using the product to ensure proper functionality and to maximize your experience.

বান্ডিল বিষয়বস্তু

Your Zoom LiveTrak L-12 Digital Mixer & Multitrack Recorder Bundle includes the following items:

• 1x Zoom LiveTrak L-12 - 12-Channel Digital Mixer & Multitrack Recorder
• 1x পাওয়ার তার
• 1x Zoom USB Cable
• 2x Zoom ZDM-1 Podcast Dynamic Microphone
• 2x Zoom ZHP-1 Headphones
• 2x উইন্ডস্ক্রিন
• 2x XLR Microphone Cable
• 2x Adjustable Tabletop Tripod
• 1x পরিষ্কারের কাপড়

Image: The bundle includes the LiveTrak L-12 mixer, two ZDM-1 microphones, two ZHP-1 headphones, two windscreens, two XLR cables, two tabletop tripods, and a cleaning cloth.

পণ্য ওভারview

The Zoom LiveTrak L-12 is a versatile digital mixer and multitrack recorder designed for musicians, podcasters, and sound engineers. It offers a comprehensive solution for mixing, monitoring, and recording audio.

মূল বৈশিষ্ট্য:

• 12 Discrete Channels: Effortlessly mix and record multiple audio sources simultaneously.
• Advanced Preamps: Equipped with high-quality, quiet preamps for professional-grade sound with minimal noise.
• কাস্টম দৃশ্য সেটিংস: Save and recall up to nine custom mix settings, including fader position, EQ, pan, and mute.
• Five Custom Monitoring Mixes: Each of LiveTrak's five monitor outputs provides a unique mix, allowing performers to create personalized headphone mixes.
• Multitrack Recording: Record 12 discrete tracks up to 24-bit/96 kHz WAV audio directly to an SD card. Tracks can be transferred for further mixing and editing.

Image: The Zoom LiveTrak L-12 digital mixer showing its faders, knobs, and display screen.

সেটআপ এবং সংযোগগুলি

Follow these steps for initial setup and connecting your equipment:

1. পাওয়ার সংযোগ: Connect the provided power cable to the DC IN port on the rear panel of the LiveTrak L-12 and plug it into a power outlet.
2. মাইক্রোফোন সংযোগ: Connect the ZDM-1 Podcast Dynamic Microphones to the XLR inputs on the mixer using the supplied XLR cables. The LiveTrak L-12 features combo jacks that accept both XLR and 1/4-inch connectors.
3. Headphone Connections: Plug the ZHP-1 Headphones into the dedicated monitor output jacks on the mixer.
4. USB সংযোগ (ঐচ্ছিক): For computer integration, connect the Zoom USB cable from the LiveTrak L-12 to your computer.
5. SD কার্ড সন্নিবেশ: Insert a compatible SD card into the SD card slot for multitrack recording.

Image: The rear panel of the Zoom LiveTrak L-12, displaying XLR/TRS combo inputs, master outputs, monitor outputs, USB ports, and the power input.

Operating the LiveTrak L-12

The LiveTrak L-12 offers intuitive controls for mixing and recording. Familiarize yourself with the layout and functions:

Channel Strip Controls:

• Each of the 12 channels features a gain knob, a one-knob compressor, a 3-band EQ (High, Mid, Low), pan control, and send EFX (effects) control.
• Use the faders to adjust the volume level of each individual channel.

রেকর্ডিং এবং প্লেব্যাক:

• চাপুন আরইসি/প্লে button on each channel to arm it for recording or to enable playback.
• Use the dedicated transport controls (Play, Record, Stop) for multitrack recording to the SD card.

Custom Scene Management:

• The LiveTrak L-12 allows you to save up to nine different scenes. Each scene stores all current mix settings.
• ব্যবহার করুন দৃশ্য buttons to save and recall your preferred configurations for different songs or setups.

পর্যবেক্ষণ মিশ্রণ:

• The mixer provides five independent monitor outputs (A-E), each with its own volume control.
• Performers can customize their individual headphone mixes, ensuring optimal monitoring during recording or live performance.

ছবি: একটি ক্লোজ-আপ view of the Zoom LiveTrak L-12's control surface, highlighting the faders, knobs, and display for mixing, recording, and monitoring.

ZDM-1 Podcast Dynamic Microphone, ZHP-1 Headphones, and Accessories

The bundle includes essential accessories to complement your LiveTrak L-12:

• Zoom ZDM-1 Podcast Dynamic Microphone: Designed for clear vocal capture, ideal for podcasting, streaming, and recording instruments.
• Zoom ZHP-1 Headphones: Comfortable, closed-back headphones providing excellent sound isolation for accurate monitoring.
• Adjustable Tabletop Tripod: Provides stable placement for your ZDM-1 microphone.
• উইন্ডস্ক্রিন: Reduces plosives and unwanted breath noise for cleaner audio recordings.
• XLR Microphone Cable: High-quality cables for reliable connection between microphones and the mixer.

Image: The Zoom ZDM-1 dynamic microphone with a windscreen on a tabletop tripod, alongside the ZHP-1 headphones.

প্রযুক্তিগত বিশেষ উল্লেখ

সমস্যা সমাধান

If you encounter any issues with your Zoom LiveTrak L-12, please refer to the following general troubleshooting steps:

• ক্ষমতা নেই: Ensure the power cable is securely connected to both the mixer and a working power outlet.
• No Audio Input: Check all microphone and line input connections. Verify that the gain knobs are appropriately set and that phantom power is enabled for condenser microphones if applicable.
• কোনো অডিও আউটপুট নেই: Confirm that master faders and individual channel faders are raised. Check headphone and main output connections and volume levels.
• রেকর্ডিং সমস্যা: Ensure an SD card is properly inserted and has sufficient free space. Verify that channels are armed for recording.

For more detailed troubleshooting, please consult the full product manual available on the Zoom webসাইট

ওয়্যারেন্টি এবং সমর্থন

Your Zoom LiveTrak L-12 Digital Mixer & Multitrack Recorder Bundle is covered by a manufacturer's warranty. For specific warranty details, registration, and technical support, please visit the official Zoom webসাইটে যান অথবা সরাসরি তাদের গ্রাহক পরিষেবার সাথে যোগাযোগ করুন। ওয়ারেন্টি দাবির জন্য আপনার ক্রয়ের প্রমাণ রাখুন।
